Co-Linear Terra-Cotta Mount Chimney Cap and Liner Kit

Product Images

Co-Linear Terra-Cotta Mount Chimney Cap and Liner Kit

Co-Linear Terra-Cotta Mount Chimney Cap and Liner Kit

Description:
Use the Terra-Cotta Mount Co-Linear Chimney Cap to vent the exhaust of your pellet or gas stove while also running...

Use the Terra-Cotta Mount Co-Linear Chimney Cap to vent the exhaust of your pellet or gas stove while also running a liner to the same chimney cap for the fresh air intake. Easily installs with pressure fit screws to your clay tile!

As low as$529.99

Product Details:

Are you in need of an extremely easy way to attach your Co-Linear Chimney Cap to your clay chimney flue tile? If so, the Terra-Cotta Mount Co-Linear Chimney Cap is a perfect choice for you. Our Co-Linear Chimney Caps are perfect for gas or pellet stoves and fireplace inserts. This kind of cap allows you to pull the fresh air required for combustion from the chimney cap while also running a separate liner for the exhaust. No need to cut through the side of the chimney for the fresh air. Simply run the 430 stainless steel flexible liner down the chimney and connect it to the Co-Linear Chimney Cap.

Our Terra-Cotta Mount Co-Linear Chimney Cap fastens right onto the terra-cotta clay flue tile. The top plate pressure screws to the tile like a traditional single flue cap and gives a great no-hassle, finished look. No drilling or cutting required! The clay tile flue should protrude through the chimney crown at least 1.5" in order for the pressure screws to grab the sides of the flue tile. We are offering the Co-Linear Chimney Cap for 8" x 13" flues tiles and 13" x 13" flues tiles. Available for a 3" exhaust and 3" air intake OR 4" exhaust and 3" air intake.

Specifications:

Features:

  • 304L stainless steel chimney cap to pressure fit to clay tile flue
  • Connect both the exhaust liner and fresh air intake liner in one cap
  • Includes 35' of 430 stainless steel flexible liner for fresh air intake
  • Includes 35' of 430 stainless steel flexible liner for exhaust
  • Includes two stainless steel hose clamps

Help & Documents:

Applications:

  • Used to vent a gas stove or gas fireplace insert into a masonry chimney along with the fresh air intake
  • Used to vent a pellet stove or pellet fireplace insert into a masonry chimney along with the fresh air intake
  • 8" x 13" Top Plate fits flue sizes between 7" to 9.25" and 11" to 13.5"
  • 13" x 13" Top Plate fits flue sizes between 11" to 13.5" and 11" to 13.5"

For connecting to a pellet stove, please choose a connector to connect the flex liner to the exhaust hole. The Appliance Connector is used to connect vertically to the top of the stove. The Tee Connector is used to connect horizontally to the back of the stove. Please choose the connector selection in the options box above.
