Square Flexible Chimney Liner Insulation Sizing Chart
March 20, 2024
Use this chart to help you select the size of the Blanket Wrap Insulation Kit that will pair with your Square shaped chimney liner. Choose your insulating blanket thickness then view which size square liners will work the best for the diameter.
1/2" Insulation |
|||
| 3" to 6" | 7" to 8" | 9" | 10" to 16" |
| 4.75" x 4.75" | 6" x 6" | 8.25" x 8.25" | 9" x 9" |
| 5.25" x 5.25" | 6.5" x 6.5" | 9.75" x 9.75" | |
| 5.5" x 5.5" | 6.75" x 6.75" | 10.5" x 10.5" | |
| 7.5" x 7.5" | 12" x 12" | ||
| 14" x 14" | |||
1/4" Insulation |
|||
| 3" to 6" | 7" to 8" | 9" to 10" | 11" to 14" |
| 4.75" x 4.75" | 6" x 6" | 8.25" x 8.25" | 9.75" x 9.75" |
| 5.25" x 5.25" | 6.5" x 6.5" | 9" x 9" | 10.5" x 10.5" |
| 5.5" x 5.5" | 6.75" x 6.75" | 12" x 12" | |
| 7.5" x 7.5" | 14" x 14" | ||
