Flexible Chimney Liner Elbow Dimensions

Our Flex Liner Elbows have laser welded seams for smooth adjusting and feature the quick connect band clamp for a secure fit every time. If your installation is tight on space, we've included the chimney liner elbow measurements below.

If you can't find a measurement, or aren't sure, give us a call! We'll be happy to assist you.



Rock-Flex Fixed Elbow Dimensions

Elbow Size:

Height A:

Height B:

Offset C:

3" x 30°

7"

9"

4"

4" x 15°

7.25"

8.25"

3.5"

4" x 30°

7"

9.5"

4.5"

5" x 15°

7.25"

8.75"

3.75"

5" x 30°

7.25"

9.75"

4.75"

5.5" x 15°

7"

8.5"

4.25"

5.5" x 30°

7.5"

10"

5.25"

6" x 15°

7"

8.5"

4"

6" x 30°

7"

10"

5.25"

Note: These numbers are approximations; each elbow may be manufactured slightly different.

Rock-Flex Adjustable Elbow Dimensions

Elbow Size:

Height A:

Height B:

Offset C:

3" x 45°

6.5"

9"

5.5"

3" x 90°

3.5"

7"

6.75"

4" x 45°

5.5"

9"

5"

4" x 90°

3.25"

7.75"

6.5"

5" x 45°

4.75"

8.75"

5"

5" x 90°

3"

8.5"

7.5"

5.5" x 45°

5.5"

10.25"

5.5"

5.5" x 90°

3.25"

9.25"

7.5"

6" x 45°

6"

10.5"

6.25"

6" x 90°

3"

9.5"

8"

Note: These numbers are approximations; each elbow may be manufactured slightly different.

You can find Rock-Flex Chimney Liner Elbows on the following pages:
